RANGER SP 570 HD 2024

RRP from $21,995

RANGER SP 570 HD 2024

  • Features
  • Specifications
  • Gallery

Features

BIG PERFORMANCE. SMALL FOOTPRINT.

The RANGER SP 570 HD  puts best-in-class 2-person utility side-by-side performance in your hands. This workhorse is equipped with features you need to get the job done, and comfort you desire for successful days on the trails or around your property.

  • GHOST GREY 2024
  • Electronic Power Steering (EPS)
  • Active Decent Control (ADC)
  • Automotive Paint
  • ProStar 570 Engine
  • 25″ Wheels
  • Aluminium Black Wheels
  • Heavy Duty features including upgraded rear driveshaft, grease nipples, HD sway bar, sealed suspension bushings, sealed ball joints and driveshaft spline seals

View current offers here

  • Capacity
    SEATS 2
  • Disc Brakes Front And Rear
    Disc Brakes Front And Rear
  • Dump Box Capacity
    226.8 DUMP BOX CAPACITY
  • Electronic Fuel Injection
    Electronic Fuel Injection
  • Electronic Power Steering Wheel
    Electronic Power Steering Wheel
  • Horse Power
    44 HP
  • Independent Rear Suspension
    Independent Rear Suspension
  • On Demand True All Wheel Drive
    On Demand True All Wheel Drive
  • Reverse Gear
    Reverse Gear
  • Roll Over Protection Structure
    Roll Over Protection Structure
  • Towing Capacity
    680.4 KG TOWING CAPACITY

ENGINE & DRIVE TRAIN

ENGINE TYPE 4-Stroke Single Cylinder
CYLINDERS-DISPLACEMENT (cc) 567 CC / 44 HP
FUEL SYSTEM Electronic Fuel Injection
TRANSMISSION/FINAL DRIVE Automatic PVT H/L/N/R/P; Shaft
DRIVE SYSTEM On-Demand True AWD/2WD VersaTrac Turf Mode. Active Decent Control (ADC) and Heavy Duty features including upgraded rear driveshaft, grease nipples, HD sway bar, sealed suspension bushings, sealed ball joints and driveshaft spline seals
COOLING Liquid

SUSPENSION / BRAKES / WHEELS

FRONT SUSPENSION MacPherson Strut 9 in (22.9 cm) Travel
REAR SUSPENSION Dual A-Arm, IRS 10 in. (25.4 cm) Travel
FRONT / REAR BRAKES 4-Wheel Hydraulic Disc
PARKING BRAKE Hand Brake
FRONT TYRES 25 x 8-12; 489
REAR TYRES 25 x 10-12; 489
WHEELS Aluminium Black

DIMENSIONS

BED BOX DIMENSIONS (L X W X H) 93 x 137 x 29 cm
FRONT/REAR RACK OR BOX CAPACITY 226.8 kg
FUEL CAPACITY 34.1 L
GROUND CLEARANCE 26.7 cm
OVERALL VEHICLE SIZE (L X W X H) 279 x 174 x 185 cm
PAYLOAD CAPACITY 453.6 kg
WHEELBASE 185.4 cm
ESTIMATED DRY WEIGHT 499 kg

FEATURES

CARGO SYSTEM Lock & Ride®
ELECTRONIC POWER STEERING Standard
HITCH TOWING RATING 680.4 kg
HITCH/TYPE Standard / 5 cm Receiver
INSTRUMENTATION 4 ” LCD Rider Information Center: Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seatbelt Reminder Light, DC Outlet
LIGHTING 50W Headlight, LED Tail
VARIANTS Off-Road
